This post describes how to handle files that are used as assets by jobs and pipelines defined on a common gitlab-ci
repository when we include those definitions from a different project.
Problem descriptionWhen a .giltlab-ci.yml file includes files from a different
repository its contents are expanded and the resulting code is the same as the one generated when the included files
are local to the repository.
In fact, even when the remote files include other files everything works right, as they are also expanded (see the
description of how included files are merged
for a complete explanation), allowing us to organise the common repository as we want.
As an example, suppose that we have the following script on the assets/ folder of the common repository:
dumb.sh
#!/bin/shecho"The script arguments are: '$@'"
If we run the following job on the common repository:
But if we run the same job from a different project that includes the same job definition the output will be different:
/scripts-23-19051/step_script: eval: line 138: d./assets/dumb.sh: not found
The problem here is that we include and expand the YAML files, but if a script wants to use other files from the
common repository as an asset (configuration file, shell script, template, etc.), the execution fails if the files are
not available on the project that includes the remote job definition.
SolutionsWe can solve the issue using multiple approaches, I ll describe two of them:
Create files using scripts
Download files from the common repository
Create files using scriptsOne way to dodge the issue is to generate the non YAML files from scripts included on the pipelines using
HERE documents.
The problem with this approach is that we have to put the content of the files inside a script on a YAML file and if it
uses characters that can be replaced by the shell (remember, we are using HERE documents) we have to escape them (error
prone) or encode the whole file into base64 or something similar, making maintenance harder.
As an example, imagine that we want to use the dumb.sh script presented on the previous section and we want to call it
from the same PATH of the main project (on the examples we are using the same folder, in practice we can create a hidden
folder inside the project directory or use a PATH like /tmp/assets-$CI_JOB_ID to leave things outside the project
folder and make sure that there will be no collisions if two jobs are executed on the same place (i.e. when using a ssh
runner).
To create the file we will use hidden jobs to write our script
template and reference tags to add it to the
scripts when we want to use them.
Here we have a snippet that creates the file with cat:
Note that to make things work we ve added 6 spaces before the script code and escaped the dollar sign.
To do the same using base64 we replace the previous snippet by this:
Again, we have to indent the base64 version of the file using 6 spaces (all lines of the base64 output have to be
indented) and to make changes we have to decode and re-code the file manually, making it harder to maintain.
With either version we just need to add a !reference before using the script, if we add the call on the first lines of
the before_script we can use the downloaded file in the before_script, script or after_script sections of the
job without problems:
The output of a pipeline that uses this job will be the same as the one shown in the original example:
The script arguments are: 'ARG1 ARG2'
Download the files from the common repositoryAs we ve seen the previous solution works but is not ideal as it makes the files harder to read, maintain and use.
An alternative approach is to keep the assets on a directory of the common repository (in our examples we will name it
assets) and prepare a YAML file that declares some variables (i.e. the URL of the templates project and the PATH where
we want to download the files) and defines a script fragment to download the complete folder.
Once we have the YAML file we just need to include it and add a reference to the script fragment at the beginning of the
before_script of the jobs that use files from the assets directory and they will be available when needed.
The following file is an example of the YAML file we just mentioned:
bootstrap.yml
CI_TMPL_API_V4_URL: URL of the common project, in our case we are using the project ci-templates inside the
common group (note that the slash between the group and the project is escaped, that is needed to reference the
project by name, if we don t like that approach we can replace the url encoded path by the project id, i.e. we could
use a value like $ CI_API_V4_URL /projects/31)
CI_TMPL_ARCHIVE_URL: Base URL to use the gitlab API to download files from a repository, we will add the arguments
path and sha to select which sub path to download and from which commit, branch or tag (we will explain later why
we use the CI_TMPL_REF, for now just keep in mind that if it is not defined we will download the version of the
files available on the main branch when the job is executed).
CI_TMPL_ASSETS_DIR: Destination of the downloaded files.
And uses variables defined in other places:
CI_TMPL_READ_TOKEN: token that includes the read_api scope for the common project, we need it because the
tokens created by the CI/CD pipelines of other projects can t be used to access the api of the common one.We define the variable on the gitlab CI/CD variables section to be able to change it if needed (i.e. if it expires)
CI_TMPL_REF: branch or tag of the common repo from which to get the files (we need that to make sure we are using
the right version of the files, i.e. when testing we will use a branch and on production pipelines we can use fixed
tags to make sure that the assets don t change between executions unless we change the reference).We will set the value on the .gitlab-ci.yml file of the remote projects and will use the same reference when including
the files to make sure that everything is coherent.
This is an example YAML file that defines a pipeline with a job that uses the script from the common repository:
pipeline.yml
Where we use a YAML anchor to ensure that we use the same reference when including and when assigning the value to the
CI_TMPL_REF variable (as far as I know we have to pass the ref value explicitly to know which reference was used
when including the file, the anchor allows us to make sure that the value is always the same in both places).
The reference we use is quite important for the reproducibility of the jobs, if we don t use fixed tags or commit
hashes as references each time a job that downloads the files is executed we can get different versions of them.
For that reason is not a bad idea to create tags on our common repo and use them as reference on the projects or
branches that we want to behave as if their CI/CD configuration was local (if we point to a fixed version of the common
repo the way everything is going to work is almost the same as having the pipelines directly in our repo).
But while developing pipelines using branches as references is a really useful option; it allows us to re-run the jobs
that we want to test and they will download the latest versions of the asset files on the branch, speeding up the
testing process.
However keep in mind that the trick only works with the asset files, if we change a job or a pipeline on the YAML
files restarting the job is not enough to test the new version as the restart uses the same job created with the current
pipeline.
To try the updated jobs we have to create a new pipeline using a new action against the repository or executing the
pipeline manually.
ConclusionFor now I m using the second solution and as it is working well my guess is that I ll keep using that approach unless
giltab itself provides a better or simpler way of doing the same thing.
